TS-SM3110-40C SFP+ 10GBASE-ER 1310nm 40km DOM Duplex LC/UPC SMF Optical Transceiver Module
share
Parameter
P/N ： TS-SM3110-40C
Form Factor ： SFP+
Type ： Single Mode
Data Rate ： 10G
Model ： ER
Connector ： Duplex LC
Distance ： ≤40km
Wavelength ： 1310nm
DetailReview(0)
Trxcom TS-SM3110-40C SFP+ 10GBASE-ER Optical Transceiver Module (SMF, 1310nm, 40km, LC, DOM)
The Trxcom TS-SM3110-40C SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 40km transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a transimpedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
| Trxcom Part Number | TS-SM3110-40C | Vendor Name | Trxcom |
| Form Factor | SFP+ | Max Data Rate | 10.3Gbps |
| Wavelength | 1310nm | Max Cable Distance | 40km |
| Connector | Duplex LC | Optical Components | DFB 1310nm |
| Media | SMF | DOM Support | Yes |
| TX Power | -6 to -0.5dBm | RX Power | -20 to -1dBm |
| Receiver Sensitivity | -16dBm | Receiver Overload | -0.5dBm |
| Operating case temperature | 0 to 70°C | Protocols | SFP+ MSA Compliant, CPRI, eCPRI |
Data Center
Telecommunications
Medical Equipment
Industrial Control
Consumer Electronics
Security System
Military Industry
