TS-SM311G-10C SFP 1000BASE-LX/LH 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
share
Parameter
P/N ： TS-SM311G-10C
Form Factor ： SFP
Type ： Single Mode
Data Rate ： 1G
Connector ： Duplex LC
Distance ： ≤10km
Wavelength ： 1310nm
DetailReview(0)
Trxcom TS-SM311G-10C SFP 1000BASE-LX/LH Duplex LC/UPC Optical Transceiver Module(SMF, 1310nm, 10km, DOM)
The TS-SM311G-10C SFP transceivers are high performance, cost effective modules supporting data rate of 1.25Gbps and 10km transmission distance with SMF. The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
| Trxcom Part Number | TS-SM311G-10C | Vendor Name | Trxcom |
| Form Factor | SFP | Max Data Rate | 1.25Gbps |
| Wavelength | 1310nm | Max Cable Distance | 10km |
| Connector | Duplex LC | Optical Components | DFB 1310nm |
| Media | SMF | DOM Support | Yes |
| TX Power | -9 to 0dBm | RX Power | -23 to -1dBm |
| Receiver Sensitivity | -23dBm | Receiver Overload | -1dBm |
| Operating case temperature | 0 to 70°C | Protocols | IEEE 802.3ah-2004, IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) Compliant |
