HALO HFJV1-2450-L21RL Compatible 10/100 Base-T Vertical RJ45 Magjack With Yellow/Green LED

Name: HALO HFJV1-2450-L21RL Compatible 10/100 Base-T Vertical RJ45 Magjack With Yellow/Green LED
Availability: InStock

Facebook

Line

Tumblr

Parameter

Brand: ： Trxcom

P/N: ： TRJD1011BDNL

Compatible Brand: ： HALO

Compatible P/N: ： HFJV1-2450-L21RL

Port: ： 1X1

Rate: ： 10/100Base-T

PoE: ： NONE-PoE

Latch: ： Vertical

LED: ： Yellow/Green

Mount: ： 0℃ to 70℃

Shield Tabs: ： No

Compatible Brand:

HALO

Compatible P/N:

HFJV1-2450-L21RL

HFJV1-2450-L12RL

Get a Quote

Consult products

DetailReview(0)

HALO HFJV1-2450-L21RL Compatible Trxcom TRJD1011BDNL 10/100 Base-T Vertical RJ45 Magjack For Switches ( Top entry, Yellow/Green LED)

The HALO HFJV1-2450-L21RL Compatible Trxcom TRJD1011BDNL supports 10/100/1000 Base-T transmission rates and complies with IEEE 802.3, UL, REACH, RoHS, ISO9001 and ISO14001 standards. It can be applied in scenarios such as industrial computers, smart electricity meters, medical care and more.

Trxcom Part Number	TRJD1011BDNL	HALO Part Number	HFJV1-2450-L21RL
Connector Type	Jack	Mounting Type	Through Hole
Number of Positions/Contacts	8p8c(RJ45, Ethernet)	Application-Lan	Ethernet(NoN PoE)
Number of Ports	1x1 Port	Speed	10/100 Base-T
Latch	UP	Cores per Port	4
Orientation	180° Angle (Right)	PCB Mount Angle	THT Solder
Shield EMI Tabs	Without	LED Option	Yellow/Green
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.654/16.60	Package Length (Inches/mm)	0.850/21.59
Package Width (Inches/mm)	0.630/16.00	Temperature	0℃ TO 70℃
Bst Circuit	Yes	AutomDX	Yes
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T、C

Quality Certifications

We strictly control product quality, including strict control of manufacturer qualifications, quality control processes and production process standards, and compliance with various certifications and safety standards. Currently, our products comply with industry standards and mainstream quality certifications, such as ISO 9001, ISO 14001, CE, RoHS, REACH, UL, etc. For more details, please visit the Compliance Center Center to get documents.
